PROFESSIONAL FEATURES

• SmartLink Aircard Compatible
• 4 programs: A, B, C; program D can operate concurrently
• 8 start times per program
• Indoor/Outdoor Rated
• English/Spanish
• Zone run times settable from 1 min. to 9 hrs. 55 min.
• Rain/Freeze sensing on/off button with Tri-Color LED indicator
• Rain delay of 1 – 7 days
• RFS5 Rain/Freeze Sensor rain delay programmable from 0 – 99 hours
• Seasonal % adjust by program, by month
• Omit time of day window, day(s) of week, and up to 7 calendar dates
• Programmable zone-to-zone delay 1 min. – 3 hrs.
• Watering days: custom days of the week, odd/even, or interval days
• Run/Soak cycles by program
• Large backlit LCD display
• Non-volatile memory – with no battery required
• Internal 120VAC/230VAC transformer with pre-installed 6’ line cord

MANUAL OPERATION

• Manual test runs each zone with zone run times from 10 sec. – 10 min.
• Manual zone operation of a single zone (1 min. to 9 hrs. 55 min.)
• Push button manual start of a program from control panel

ON-SITE DIAGNOSTIC/TROUBLESHOOTING FEATURES

• Fault review displays all faults, including open and shorted zones
• Test function using on-board multi-meter
• Built-in valve locator
• Backtrack Stored Program™

ADDITIONAL FEATURES

• Zone-to-zone delay
• Master valve timing sequence with zone valve programmable
• Master valve/pump start operation assignable On/Off by zone
• Clear program function
• Clear All function
• Grow-In Program
