Features

• Bayonet protective cap.
• NIR2 feature (Nozzle Insertion/Radius Reduction) on all models eliminates the need to remove the cap for nozzle adjustments.
• Eight interchangeable Acu-Cover nozzles ranging from 1.0 to 9.5 gpm (0,23 – 2,16 m3/hr).
• Seven optional low-angle nozzles (13°) for windy areas or for throwing under trees.
• Proven reliability of the water driven gear motor.
• 6012 Pro pops up a full 12” (30,5 cm). Ideal for shrubs and ground cover areas, at the base of hillsides where risers are not appropriate and where liability is a concern.
• Click-Set® collars are quick and easy to adjust.
• Continuous 360° rotation or part-circle adjustable 40° to 310°.
• Ratcheting slip clutch protects gears and motor from damage while adjusting turret for part-circle adjustments – wet or dry.
• Wrench, piston clamp and installation instructions included (Model 6001 has no clamp).

OPERATING RANGE:
20-65 psi (1,4 –4,5 bar) (6000, 6001, 6002)
25-65 psi (1,7 – 4,5 bar) (6005, 6012)

MAXIMUM PRESSURE: 75 psi (5,2 bar)

DISCHARGE: 1.0 to 9.5 gpm (0,23 – 2,16 m3/hr)

SPRAY TRAJECTORY: 25°

EXPOSED CAP DIAMETER: 1 7⁄8” (4.7 cm)

CAP DIAMETER: 2 7⁄8” (7.3 cm)

TYPE OF CAP: Rubber with locking screw

INLET SIZE: 3⁄4” (19 mm) female (NPT and BSP)

SCREEN MESH: .045 sq. in. (1,14 mm2) /1150 micron

ADV MODELS: Holds back up to 10’ (3 m) difference in elevation
